This series heat pump can work in very low climate area down to -35℃. The heat pump isequipped with EVI compressor and high efficiency in low temperature conditions, its heating performance is higher by 50%-80% than normal heat pump. It is widely used in cold area and even work well at -35℃, can be matched with fan coil, floor radiator heating, it is suitable for villa, hotel, office, etc.
|
Model
|
YINI-100S-DCN
|
|
Ambient temp.range
|
-35~+43℃
|
|
Power supply
|
380V 3N~50Hz
|
|
Electric shock proof grade
|
Class I
|
|
Protection grade
|
IPX4
|
|
Heating Capacity/COP
|
33.0KW /4.3
|
|
Cooling Capacity/COP
|
27.0KW /2.8
|
|
Low-temperature heating(A-12W41)/COP
|
20.0KW /2.3
|
|
Normal temperature heating(A7W45)/COP
|
32.0KW /3.6
|
|
Rated cooling input power
|
9.6KW
|
|
Low temperature heating input power
|
8.7KW
|
|
Normal temperature heating input power
|
4.5KW
|
|
Max.working current
|
25A
|
|
Compressor
|
Scroll
|
|
2 pcs
|
|
Fan
|
2 pcs
|
|
Max. water temperature
|
60℃
|
|
Water yield
|
2500 L/h
|
|
Noise
|
65 dB(A)
|
|
Dimension (width×depth×high)
|
1530×750×1370 (mm)
|
|
Packing dimension(width×depth×high)
|
1650×850×1470 (mm)
|
|
Net weight
|
350KG
|
|
Gross weight
|
380KG
|
