DC inverter Heat Pump, with the advanced DC inverter and EVI technology, can save you 80% heating cost compare with the traditional heating device like gas/fuel boiler and electrical heater. It heats fast and works perfectly with the radiator and floor heater to provide you a comfortable living environment even in very cold winter. It is one of the best heating devices available today.
Main Features
1) Twin rotary compressor with inverter control – DC inverter technology control the heat pump output according to the household's energy requirements. Low waste of the power!
2) Electronic Expansion Value allows the accurate refrigerant go through under different working conditions.
3) Intelligent controller and LCD displaying.
4) Safely operation with multi-protections.
5) Auto defrosting function.
6) Hydrophilic coating air exchanger and plate heat exchanger all available.
OPTIONAL:
Galvanized metal cabinet or stainless steel cabinet all available.
R410a, R22, R407c refrigerant is available.
|
DC Inverter Heat Pump Series
|
|
Model
|
YINI-080-BPCN |
|
Ambient temp.range
|
-35~+43℃
|
|
Power supply
|
220V~240V 1N~50Hz
|
|
Electric shock proof grade
|
Class I
|
|
Protection grade
|
IPX4
|
|
Heating capacity/COP
|
23.5KW /3.30
|
|
Rated cooling capacity
|
20KW /2.9
|
|
Rated heating capacity
|
23.0KW /3.3
|
|
Compressor
|
Scroll
|
|
Rated refrigerating input power/current
|
5.16KW /23.5A
|
|
Rated heating input power/current.
|
4.68KW /21.2A
|
|
Max. working current
|
Max. working current
|
|
Max. working pressure of heat exchanger
|
4.2 Mpa
|
|
Temperature range of refrigeration outlet
|
5~15℃
|
|
Heat outlet temperature range
|
25~58℃
|
|
Water yield
|
2500 L/h
|
|
Refrigerant type/Weight
|
R32-R410a/4.4 kg
|
|
Noise
|
≤59 dB(A)
|
|
Dimension (width×depth×high)
|
1120×440×1360 (mm)
|
|
Packing dimension(width×depth×high)
|
1220×560×1560(mm)
|
|
Net weight
|
150KG
|
|
Gross weight
|
180KG
|
