Model No.︰YINI-050S-RS

Brand Name︰AIRYINI

Country of Origin︰China

Unit Price︰US $ 1650 / pc

Minimum Order︰1485 pc

Inquire Now

Product Description

This commercial hot water heat pump is the best solution for hot water supply of commercial project, and can work with advantages of high safety, stability, much convenience, energy saving, and environment friendly, which assures 24 hours comfortable hot water using. It is widely used in hot water project of school, hotel, hospital, supper market and other large building, which needs large water volume supply.

Commercial hot water heat pump series

Model

YINI-050S-RS

Heating mode

Circulating+Direct heat

Ambient temp.range

-15~+43℃

Rated heating capacity

18KW

COP

4W/W

Max. Running Current

9.7A

Power supply

380V 3N~50Hz

IP Code

IPX4

Safety function

High and low pressure protection, Overload protection, Temperature protection, Power phase sequence protection, etc.

Refrigerant type/weight

R407C/2.0kg

Compressor QTY

1 PCS

Compressor type

Scroll

Max. outlet water temperature

60℃

Water side heat exchanger type

Casing/high efficiency tank

Direct heat waterpipe nozzle

G1''Internal thread (inch)

Circulating waterpipe nozzle

G1''Internal thread (inch)

Air out type

Top discharge

Fan motor QTY

1 PCS

machine dimension (width × depth × high)

750×690×1070 (mm)

Packing dimension (width×depth×high)

800×740×1200 (mm)

Net weight

130KG

Gross weight

150KG

Detailed Images

Main Features

1) Copeland scroll compressor, quiet and high efficiency.

2) High efficiency heat exchanger.

3) 600 stage adjustment precision electronic expansion valve.

4) Schneider electrical components.

5) Intelligent controlling system.

6) Intelligent EE valve, excellent efficiency at different ambient temp.

7) Easy installation and LCD operation.

8) Automatically defrosting.





Optional:  R410a, R22, R407c refrigerant is available.

Product Image
